1. The machine must be kept clean and in good working condition in order to achieve the best performance. The generation of waste material will affect the operation of the machine, so it must be removed regularly. The conveyor belt must be cleaned regularly with a brush.
2. The photoelectric eye and reflector on the machine must be cleaned regularly with a smooth dry cloth, because the dirty electric eye will cause the machine to stop.
3. Check whether the motor is in good working condition and whether the brake lining of the motor is worn. If it is worn, it must be replaced. Only qualified personnel can overhaul the electric motor.
4. When using the glue sprayer, after completing a task, apply a small amount of grease or silicone on the nozzle, and clean the nozzle with a needle or compressed air if necessary.
5. The lower paste cylinder needs to be cleaned frequently. Remove the upper cover, remove the glue tank, and clean the glue tank and paste wheel.
6. Depending on the degree of contamination of the spiral guard, clean and lubricate it and apply a thin film of light oil.
7. It is necessary to inject butter into the sliding sleeve on the chrome rod once a month, and each sliding sleeve is equipped with a grease nozzle.
8. Properly tension the drive chain on the lead screw every six months and apply chain oil for protection.
9. There are self-lubricating copper sleeves inside the parts. The copper sleeves are easy to wear and need to be checked and replaced regularly
10. Long-term operation will cause the belt to stretch. It is necessary to check and tighten the drive belt every six months. 11. Regularly check and clean the air filter, a clogged filter will reduce the flow rate and should be replaced regularly.
12. The upper conveyor is an important part of the folder-gluer and needs to be fully maintained and calibrated. 13. The transmission belt needs to be regularly checked and tensioned, and the long-term operation will stretch the belt.
14. Replace the worn transmission belt. When replacing the belt, it must be noted that the direction of the belt arrow is consistent with the machine's running direction.
15. Regularly replace the paper feed belt. The paper feed belt is a belt with a high friction coefficient on the surface. If there is no certain friction, it is not conducive to paper output. Therefore, when the belt surface wears out after a period of use, it must be replaced.
Post time: Dec-29-2022
